Plywood Veneer Peeling Machine
Wood veneer peeling machine is a very technical equipment in plywood production line . The veneer peeling machine can be used together with veneer roller dryer . It is one of the main machines for plywood production and can be used for rotary cutting the round wood with a diameter less than 500mm with the high utilization rate of wood. Suits the production of high-level plywood and other woodworking industries. Making the high-quality rotary peeled wood veneers. Except for veneer peeling machine , plywood veneer dryer and face veneer dryer also are normal machines for plywood production line.
Spindleless veneer peeling machine is used for making veneer. This veneer peeling machine is designed for the rotary cutting of the logs with different hardness. All the motors adopt full servo motors, the speed of the rotary cutting is stable, the precision of high-speed rotary cutting is guaranteed, and the quality of the veneer is high.
Product Parameters of Veneer Peeling Machine
log peeling length | 970mm-1270mm |
veneer peeling width range | 660-2600mm
|
veneer thickness peeling range | 1.0-4.0mm |
Max. log diameter | 650mm |
min.core veneer after peeling | 38mm |
peeling speed | 48m/min |
Single roller motor | 11kw*2pcs |
Double roller motor | 11kw*2pcs |
feeding motor power | 11kw |
clipper and rubber roller motor | 5.5kw+2.2kw |
Total power | 62.7kw |
Leftover core clapper | pneumatic |
single double roller diamenter and type | 125mm(diamond shape, chromeplate) |
Main reducer model | R87 hardened gear surface |
Total weight | 13000kgs |
Overall dimension | 5800*2300*1500mm |
Certification
Factory
Our Services
Pre-sale services:
1) Provide the free consultation of all Core Veneer Dryer Machine
2) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
3) Welcome to visit our factory
Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.
After sale services:
1) 24 hours online service
2) Provide the VIDEO with Install and debug the equipment
3) Provide technical exchanging
4) Door to door service is possible
Packaging & Shipping
